C6 Z06 Engine Upgrade Stage 3 7.0L

Regular price $0.00 Available

Title

C6 Z06  7.0L (427 cu. in.) Engine Upgrade Package Stage 3

600 Plus HP

Call For Pricing

  • Custom Darton MID sleeved & machined LS6 block
  • MTI Racing 240cc Stage 4 CNC machined cylinder heads
  • MTI Racing custom profile camshaft
  • Callies 4340 forged steel crankshaft
  • New GM Z06 oil pump
  • MTI Racing specific forged aluminum pistons
  • Forged steel connecting rods
  • Callaway "Honker" cold air induction
  • MTI Racing long tube stainless steel headers
  • MTI Racing 3" dominator stainless steel cat-back exhaust
  • MTI Racing Stage 3 kevlar clutch assembly for six speeds
  • Custom transmission programming and stall converter for automatics
  • Custom computer programming and dyno tuning pre and post installation

Machine work and assembly:

  • All of our 427 cu. in. engines are custom built and dynoed in our engine building facility in Dawsonville, Ga. (Formerly Ernie Elliotts engine facility)
  • We start with a new LS6 block and use a Darton Sleeve kit. They manufacture the highest quality sleeve available.
  • A block pro five axis CNC vertical mill with fluid cooling is used for all machine work. This allows for tolerances to be held within one/half thousands of an inch.
  • All machining operations are referenced off the crankshaft centerline.
  • All required stress relieving is done using the formula 62 machine built by Stress Relief Engineering.
  • Decking of blocks is accoomplished using a custom flycutter with CBN/PCD inserts.
  • Every cam is computer checked for lift, duration, timing and centerline. Then it's degreed in the block for precise alignment.
  • All rings are file finished, deburred and checked for proper arc.
  • After engine installation, your vehicle is tuned on our chassis DynoJet dyno system.

Note: All pricing with exchange. Specs, pricing and availability are subject to change without notice. Call for information on your specific application.
